Appendix 1 List of Digilite® DL500 Spare Parts and Accessories
Description Protec Stock Code
Standby battery inter connection lead N 41-796-44
12V 3.3Ah VRLA battery ( Online OL3.3-12 ) N 13-120-24
Digilite® DL500 spares kit N 62-585-74
Digilite® DL500 user manual N 93-582-00
Digilite® DL500 Installation & commissioning manual ( this manual ) N 93-582-01
Digilite® DL500 programming manual N 93-582-02
Digilite® DL500 loop commissioning booklet N 93-582-03
Digilite® DL500 TCP/IP Interface PCB SF 40-097-45
Digilite® DL500 TCP/IP Interface Data Cable NK 12-957-58
Appendix 2 Digilite® DL500 Mechanical Dimensions
All dimensions are shown in mm.
