Environmental and Fixing
Ambient Temperature Range -10 to 45 degrees Celsius ( no condensation, or icing )
Humidity Limits 95% RH ( no condensation, or icing )
Environment
Meets IP30 if mounted in a dry position that does not exceed the temperature
and humidity limits given
Mounting 3 points surface mount or flush ( no bezel required when flush mounting )
Dimensions See Appendix 2
Communications Loop Cabling Requirements
Recommended Cable Type
Twin core twisted pair screened or twin core screened
( the screen must be connected to earth )
Four core cable must not be used. Typical cable type is Belden 8719
Recommended Cable Gauge 1,0mm
2
to 2,5mm
2
cross sectional area
Maximum Cable Resistance 16Ω per conductor ( dependent on loop volt drop calculations )
Maximum Cable Capacitance 0,22µF ( 220nF ) between conductors
Maximum Cable Distance 1,5km ( dependent on loop volt drop calculations )
Auxiliary Wiring ( Control Inputs and Global Relay ) Cabling Requirements
Recommended Cable Type
Twin core twisted pair screened or twin core screened
( the screen must be connected to earth )
Recommended Cable Gauge 1,0mm
2
to 2,5mm
2
cross sectional area
General Specifications
Loop Driver Output Capability 600mA average, 1,2A peak
Auxiliary 24V Output Current
150mA maximum ( limited by monitored, self resetting thermal 'fuse' ). Any
overload must be completely removed to clear a fault condition
Auxiliary 24V Fault Thresholds
An ‘Aux Supply Fault’ is generated when the voltage on the
Aux. 24V output drops to 75% of the panel running voltage
Control Input 1 and 2 Trigger Levels 50Ω or less for 1 second to activate. Open circuit to de-activate
Global Fault Relay Output Volt free changeover contacts rated at a maximum of 1A at 24V dc
