USER MANUAL
Page
165
3-4-4-
4.
CPU Configu
ration
This menu
provides ad
vanced CPU settings and som
e
inform
atio
n about CPU.
CPU Configura
tion S
creen
BIOS Setting
Options
Description/Purpose
Socket 0 CPU
Inform
ation
Sub-Menu
Reports CPU I
nform
atio
n
CPU Speed
No changeable options
Reports the current CPU Speed
64
-bit
No changeable options
Reports if the pro
cessor supports Intel
x86-64 (amd64) implemen
tation.
Lim
it CP
UID
Maxim
um
- Disabled
- Enabled
Enables for legacy operating sy
stems to
boot p
rocessors with
extended CPUID
function
s. When this option is enabled
,
the processor will lim
it the maxim
um
CPUID input value to 03h when
171
