Chapter
2
System
Configuration
PA
-6225
SERIES
US
ER MANUAL
Page
61
2-6-1-
1.
Power Sw
itch Selection
JP12V:
Power Sw
itch Selection
SELECTION
JUM
PER SETTING
JUM
PER ILLUSTRATI
ON
OFF
1-2
3
1
JP12V
ON
(Default)
2-3
3
1
JP12V
2-6-1-
2.
RS
-
232 S
erial Interface Connector
CN1
:
RS
-
232
serial interface waf
er
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
GND
9
NC
2
TXD
10
NC
3
RXD
11
NC
4
DTR
12
NC
5
DSR
13
NC
6
RTS
14
NC
7
CTS
15
NC
8
+12V/+5V
16
NC
1
16
CN
1
67
69
