protech PA-6225 User Manual

Chapter 2 System Configuration
PA-6225 SERIES USER MANUAL
Page 63
2-7-2. SYSKING
112
CN
SYSKING MSR Board Component Locations
2-7-2-1. Main Connector
CN:
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
+5V Vcc
7
NC
2
K-DATA
(Host to MSR)
8
NC
3
K-CLK
Host to MSR
9
NC
4
P-DATA
(MSR to Keyboard)
10
NC
5
P-CLK
(MSR to Keyboard)
11
Signal Ground
6
NC
12
Signal Ground
112
CN
