Chapter
2
System
Configuration
PA
-6225
SERIES
US
ER MANUAL
Page
35
2-4-13
.
Pow
er Button Connectors
SW1_1,
SW1_2:
Power Button connectors
PIN
ASSIGNMENT
1
+3.3V
2
GND
2-4-14. LED Bac
klight Pow
er Control Selec
tion
JP12:
LED backlight pow
er
control connectors
SELECTION
JUM
PER SETTING
JUM
PER ILLUSTRATI
ON
On
(Default)
1-3
2-4
2
1
6
5
JP12
Off
3-5
4-6
2
1
6
5
JP12
2
1
SW1_1
SW1_2
41
43
