2-5-2-4. Auto-Cutter Connector
CUT_CN1: Auto-cutter Connector
PIN
ASSIGNMENT
FUNCTION
1
NC
Unused
2
Vcs
Power supply of the Home
position sensor
3
GND
GND of the Home position
sensor
4
CUTS
Signal of the Home position
sensor
5
2B-1
Auto-cutter motor drive signal
6
2B-2
Auto-cutter motor drive signal
7
2A-1
Auto-cutter motor drive signal
8
2A-2
Auto-cutter motor drive signal
9
1B-1
Auto-cutter motor drive signal
10
1B-2
Auto-cutter motor drive signal
11
1A-1
Auto-cutter motor drive signal
12
1A-2
Auto-cutter motor drive signal
2-5-2-5. Paper-Near-END Sensor Connector
CN2: Paper-near-end sensor connector
PIN
ASSIGNMENT
FUNCTION
1
Vns
Power supply of the near end
sensor
2
NS
Signal of the near end sensor
3
GND
GND of the near end sensor
12
1
CUT_CN1
13
CN2
