Chapter 2 System Configuration
PA-6225 SERIES USER MANUAL
Page 51
PIN
ASSIGNMENT
FUNCTION
30
GND
Head GND
31
LATCH
Print data latch
32
24V
Head drive power
33
24V
Head drive power
34
24V
Head drive power
35
24V
Head drive power
36
24V
Head drive power
37
24V
Head drive power
38
NC
Unused
39
PS
Signal of the out-of-paper
sensor
40
Vps
Power supply of the out-of-
paper sensor
41
GND
GND of the platen position/
out-of-paper sensor
42
HS
Signal of the platen position
sensor
43
NC
Unused
44
FG
Frame GND
45
FG
Frame GND
46
NC
Unused
47
2A
Motor drive signal
48
1B
Motor drive signal
49
1A
Motor drive signal
50
2B
Motor drive signal
