Chapter
2
System
Configuration
PA
-6225
SERIES
US
ER MANUAL
Page
39
2-4-21
.
MSR/Card Re
ader Connectors
PS/2_1,
PS
/
2_2
:
MSR/Card read
er connectors
PIN
ASSIGNMENT
1
KB_CLK (Output)
2
KB_CLK_C (Input)
3
KB_DATA_C (Input)
4
KB_DATA (Output)
5
+5V
6
GND
2-4-
22
.
SA
TA
& S
A
TA
Pow
er Connec
tors
SATA1, SATA2:
Ser
ial ATA connectors
PIN
ASSIGNMENT
1
G1
2
TX+
3
TX
-
4
G2
5
RX
-
6
RX+
7
G3
Note:
SAT
A1 only
supports the optional RAID function on board.
JPWR_4P1
, JPWR_
4P2
:
Serial ATA po
w
er connectors
PIN
ASSIGNMENT
1
VCC
2
GND
3
GND
4
VCC12
Note:
J
PWR_
4P1 o
nly
supp
orts the o
ptional RAID fun
ctio
n on board
6
1
PS/2_1
6
1
PS/2_2
1
7
SATA1/
SATA2
/
1
4
JPWR_4P1/
JPWR_4P2
/
45
47
