protech PA-6225 User Manual

Chapter 2 System Configuration
PA-6225 SERIES USER MANUAL
Page 41
2-4-24. Mini-PCIe / mSATA Connector
SLOT1: Mini-PCIe connector, USB function not supported.
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
WAKE#
2
+3.3V
3
Reserved
4
GND
5
Reserved
6
+1.5V
7
CLKREQ#
8
Reserved
9
GND
10
Reserved
11
REFCLK1-
12
Reserved
13
REFCLK1+
14
Reserved
15
GND
16
Reserved
17
Reserved
18
GND
19
Reserved
20
Reserved
21
GND
22
PERST#
23
PERn2
24
+3.3SB
25
PERp2
26
GND
27
GND
28
+1.5V
29
GND
30
SMB_CLK
31
PETn2
32
SMB_DATA
33
PETp2
34
GND
35
GND
36
NC
37
GND
38
NC
39
+3.3V
40
GND
41
+3.3V
42
Reserved
43
GND
44
Reserved
45
NC
46
Reserved
47
NC
48
+1.5V
49
NC
50
GND
51
Reserved
52
+3.3V
1
2
15
16
17
18
51
52
SLOT1
