Chapter 2 System Configuration
PA-6225 SERIES USER MANUAL
Page 48
2-5-2. Printer Board: MB-1030
1
1
5
13
4
CN3
CN2
4
14
1
1
1
50
12
1
1
9 10
2
CN1
CUT_CN1
PRINT_CN1
COM1
USB_CN1
24V_CN1
MB-1030 Printer Board Component Locations
