protech PA-6225

Chapter 2 System Configuration
PA-6225 SERIES USER MANUAL
Page 59
2-5-3-6. Terminal Assignment Connector
CN5: Terminal assignment connector
PIN
ASSIGNMENT
FUNCTION
1
FEED
Feed signal
2
RESET
Reset signal
3
GND
GND
4
ST1
Status signal
5
ST2
Status signal
6
ST3
Status signal
7
ST4
Status signal
8
GND
GND
9
DRS
Drawer sensor signal
10
DSW
Drawer switch signal
11
Vdu
Drive terminal for the drawer
(Vp side)
12
GNDdu
Drive terminal for the drawer
(GND side)
13
GND
GND
14
NC
Unused
1
14
CN5
