Chapter
3
Software
PA
-6225
SERIES
USER MANUAL
Page
186
3-4-5-
1.
North Bridg
e
North Bridg
e S
creen
BIOS Setting
Options
Description/Purpose
Intel IGD
Configu
r
ation
Sub-m
enu
Configu
r
es Graphic Settings.
Memory
Inform
ation
No changeable options
Displays th
e DRAM inform
atio
n on
the platform.
To
tal Mem
ory
No changeable options
Displays th
e DRAM size
192
194
