[3] To select Alphanumeric characters for a channel name press the key of rotate the
rotary dial Knob until the desired character is displayed.
Press the key to advance the cursor to the next character position and repeat the
procedure until all characters are entered.
F1
Note:
Numeric characters from to may also be entered from the keypad.
0 9
[4] Pressing the key will store the channel name into memory as shown in the
figure in section 5-1.
ENTER
[1] Press the key to highlight the icon. Press the key or rotate
the dial knob until the letter of N appears in the reversed contrast cursor block.
[5] Example: To enter the Channel name NHK: 1 in to the channel memory use the
following procedure: (See the below figure.)
F1 NAME
[2] Press the key to enter the second character. Press the key or rotate
the dial knob until the letter of H appears in the reversed contrast cursor block.
F1
[3] Enter the remaining of the characters in the channel using steps 1 and 2
[4] Press the key after the last character in the Channel name to store the name in
memory.
CLR/.
Note:
When the Key is pressed a space will be entered as a character and the cursor
Will advance to the next position to the right.
CLR/.
31
31
