Proton Products SL mini and SLR mini Series Speed and Length Gauges Instruction Manual - issue 1s
Configuration by input parameters:
This interface may be configured by writing to the following input parameters:
Input parameters
DW
Bit
Comment
Unit
Range/Remark
Default
4
Batch mode LOP closure time
1=10ms
1~500 (10ms~5s)
50
16
Logic output function
0~3
LOP1 function
0=Gauge OK
1=Gauge measuring speed
2=Preset length 1 / Batch length
3=Preset length 2 / Batch number
4=Good reading
5=Object detected
6=Gauge too hot
0
4~7
LOP2 function
2
8~15
Not used
3
18
Good Reading threshold
1=1%
60%
