page 49
Industrial Power Corruptor Manual Rev 1.00
cursor in a graph, hold the left mouse button down, and slide the cursor
left or right.
Then align all of the graphs by clicking on the yellow cursor button.
To restore the default left-right values, click on the button with the
exclamation mark.
You can drag the yellow cursor left or right on each graph (the other
cursors will track the changes you make).
The text at the top of the
graph will show you the position of the cursor, and the value of the
graph at that time.
You can zoom and scroll each individual graph vertically, too. Just
click on the button to the left of the graph, then place the cursor in the
graph, hold the left mouse button down, and slide the cursor up or
down.
Click on the clipboard icon button, to the left of the graph, to copy
the graph to your computer's clipboard.
You can then paste it into any
compatible Windows program, such as Microsoft Word. (You may want
to use the Options drop-down menu to choose "Printer-friendly graphs"
if you want to conserve printer ink.)
