Page 4
Product Specification
Product SpecificationProduct Specification
Product Specification
Physical
Wall Mount
Outside dimensions 130 x 130 x 60 mm
Weight Nominal 0.65 kg
Enclosure material/description ABS base with Polycarbonate lid,
flammability rating UL94HB
Cable entry detail underside fitted with 3 x M20, nylon cable
glands suitable for 6 – 12mm cable
Transducer cable extensions 2-core screened
Maximum separation 1000 m
Environmental
IP Rating (Wall) IP66/67
Max. & min. temperature (electronics) -20 ºC to +50 ºC
Flammable atmosphere approval Safe area: compatible with approved dB
transducers (see transducer spec' sheet)
CE approval EMC approval to BS EN 50081-1:1992 for
emissions and BS EN50082-2:1995 for
immunity,
and to BS EN61010-1:1993 for low voltage
directive
Performance
Accuracy 0.25% of the measured range or
6 mm (whichever is greater)
Resolution 0.1% of the measured range or 2 mm
(whichever is greater)
Max. range Dependant on transducer (maximum 40m
dB40)
Min. range Dependent upon transducer (minimum zero
dB Mach 3)
Rate response fully adjustable
Echo Processing
Description DATEM (Digital Adaptive Tracking of Echo
Movement)
Outputs
Analogue output 0 to 5VDC into minimum load 10KΩ
non-isolated (user programmable and
adjustable) 0.1% resolution
Serial Port RS232 for programming and data extraction
Volt free contacts, number and rating 2 form "C" (SPDT) rated at 2A at 240V AC
Programming
PC programming (standard) via RS232 using supplied software
Remote programming (optional) via RS232 using optional hand held
calibrator
Programming security Via passcode (user selectable and
adjustable)
Programmed data integrity Via non-volatile RAM
