Page 20
There are two main operating modes for your blackbox, Run Mode and
Program Mode. There is also a Test Mode, used for checking the set-up.
All modes are now described.
Run Mode
Run ModeRun Mode
Run Mode
This mode is used once the blackbox has been set up in program mode. It is
also the default mode that the unit reverts to when it resumes operation after
a power failure.
When the blackbox is switched on for the first time, it will provide an output
proportional to the distance from the transducer to the target, in metres. All
relays by default are switched off.
If either the PC Programming Software (standard) or the Hand Held
Calibrator (optional), are connected to the blackbox, via the RS232
interface, whilst the blackbox is in the RUN mode then the current
measurement will be displayed, dependent on mode and measurement unit's
chosen.
After programming is complete, any relays that are set will operate when the
measurement reaches the relevant setpoint.
