Operating the Controls
Operating the ControlsOperating the Controls
Operating the Controls
Display
The display on both the PC Programming Software (standard) and the Hand
Held Calibrator (optional) are identical, and when connected to the blackbox
via the RS232 interface, provides information on the current mode of
operation.
Whilst in the Run Mode it will display the current level reading and its units
of measure, along with status messages with regards to the Transducer, Echo
reception and Fail Safe Mode. When in the Program mode the display is
used to read information on the Menu System, Parameter Number and
parameter details and values, which can be entered. During Test Mode the
display is used to monitor the simulated level.
1234.56
mm
1) Main Display
, 6 digit numeric display:
Run Mode, current measurement displayed, dependent on mode and
measurement unit's chosen, and value of Hot Key functio
Program Mode, displays parameter number and values entered for
parameters.
Test Mode, displays simulated level.
2) Auxiliary Display
, scrolling twelve digit alpha numeric display
Run Mode, displays measurement units (P104), status messages on
signal and transducer, detail of Hot Key function selected.
Program Mode, displays Menu and Sub Menu headings, parameter
details and options.
1
2
