Pulsar Blackbox User Manual

Page 21
LED’s
There are two LED’s which can be seen through the lid, of the blackbox
enclosure, which will indicate the operational status of the unit whilst in
RUN mode, as follows:
LED 1
Green
LED 2
Red
Run Mode
Off
Off
No power to uni
t
Constant
On
Constant
On
Internal Error
Slow
Flashing
Slow
Flashing
Transducer fault
Off Slow
Flashing
Failed Safe /Loss of Echo
Slow
Flashing
Off Healthy signal unit working
normally.
Program Mode
Program ModeProgram Mode
Program Mode
This mode is used to set up the blackbox or change information already set.
You must use either the PC Software supplied (standard) or alternatively the
unit can be set up with a Hand Held Calibrator (optional), both of which
must be connected to the blackbox via the RS 232 Serial Interface.
Entering a value for each of the parameters that are relevant to your
application provides all the programming information.
How to Access Program Mode
To enter program mode, you simply enter the passcode, via the keypad on
the PC Programming Software (standard) or the Hand Held Calibrator
(optional), followed by the ENTER key. The default passcode is 1997, so
you would press the following:
