Page 19
Menu Keys
The menu keys are used to navigate around the built in menu system and
have the following functions:
Menu Key Function
1) Arrow keys for moving left and right around the menu
system.
2) Used in test mode to simulate the level moving up and
down.
1) Used to confirm each action (for example select a
menu option) or when entering a parameter number or
value.
2) Used to confirm questions asked by your blackbox
such as before restoring factory defaults.
Used to navigate up a level in the menu system, and back
to run mode.
Used to cancel a value entered in error.
Numeric Keys
These keys are used for entering numerical information during
programming.
