Page 41
P9
98
SM
S
D
ays
This para
m
eter will de
termine on which d
ays the SMS messa
g
e is acti
ve and
is
entered
as
a
Boolean
value
equating
to
the
total
o
f
the
days
that
the
SMS
message is required
to be active.
Mon
Tue
Wed
Thu
Fri
Sat
Sun
1
2
4
8
16
32
64
Add together an
y
combination up to
a m
aximum o
f 127 (every day).
Examples:
21 = Mo
n, Wed, Fri.,
31 = Mo
n to Fri.,
10 = Tue and T
hu
.
46
48
Table of Contents
Default Chapter
5
Table of Contents
5
Chapter 1 Start here
7
About this Manual
7
About the Blackbox Range
8
Functional Description
9
Product Specification
10
Chapter 2 Installation
12
Power Supply Requirements
12
Location
12
Dimensions
14
Terminal Connection Details
16
Voltage Selector and Fuse Location
18
Preparation for Operation
20
Maintenance
20
Chapter 3 How to Use Your Blackbox Level System
21
PC Handheld Programmer (Standard)
21
Communication Port Configuration
22
Handheld Communicator (Optional)
22
Operating the Controls
23
Display
23
Keypad
24
Run Mode
26
Led's
27
Program Mode
27
How to Access Program Mode
27
Test Mode
29
Led's
30
Using the RS232 Serial Interface
30
Parameter Defaults
31
Factory Defaults
31
Chapter 4 Programming Guide
32
Level
32
Example 1 Level Measurement
32
Example 2 Alternating Control (Pump Down)
34
Chapter 5 Parameter Guide
36
Menu System Diagrams
36
Top Level Menu
36
Application Menu
36
Relays Menu
37
Data Logs Menu
37
Display Menu
38
Output Menu
38
Compensation Menu
38
Stability Menu
39
Echo Processing Menu
39
System Menu
40
Test Menu
41
Parameter Listing
42
Application Parameters
42
Operation
42
Dimensions
43
Remote Alarm
45
SMS Time
46
Relay Parameters
48
Relay Type
48
Alarms
49
Control
52
Common Parameters
54
Data Log Parameters
55
Temperature
55
Display Parameters
56
Options
56
Failsafe
56
Output Parameters
57
Range
57
Operation
57
Setpoint
58
Limits
58
Trim
58
Failsafe
59
Compensation Parameters
60
Offset
60
Temperature
60
Stability Parameters
61
Damping
61
Filters
61
Echo Processing Parameters
62
Transducer Status
62
System Parameters
63
Passcode
63
System Information
63
Date & Time
64
Daylight Saving Time
64
Test Parameters
68
Simulation
68
Hardware
69
Chapter 6 Troubleshooting
70
Parameter Record
71
Other manuals for Pulsar Blackbox
Quick Start Manual
2 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Pulsar Blackbox and is the answer not in the manual?
Ask a question
Pulsar Blackbox Specifications
General
Brand
Pulsar
Model
Blackbox
Category
Control Systems
Language
English
