Page 47
The third parameter determines if the control is fixed or alternating.
P212, 222 Relay Control ID
P210, 220 = 2 (Control)
P211, 221 = 1
ID Description
1= Fixed
All control devices are used to
assist each other (run at the same
time) and each device has its own
setpoints. (‘ ON’ P213, 223 &
‘OFF’ P214, 224).
3= Alternate
All control devices are used to
assist each other (run at the same
time). With each device having its
own setpoints, (‘ON’ P213, 223
& ‘OFF’ P214, 224) but each
time all devices have stopped,
then the setpoints are sequentially
rotated between the devices to
ensure equal usage.
The fourth parameter, and fifth parameter, are set to determine the switch
points, “ON” and “OFF” for the relay. See control function, table (P211,
221, 231) for further information.
P213, P223 - Relay Setpoint 1
