PYE OLYMPIC M201 - Page 85

SWITCHING MODULE AT27596 (12)
Electrial Items
Description 
Part No. 
Remarks/Code/Band
Diode BAX16 
FV05841 
D1
Miscellaneous Items
Relay 
FRO3971

R LS
PWB Assembly 
AT12393
ANTENNA FILTER MODULE AT27599/— (13)
A Band

148 — 174 MHz 
AT27599/01
M1 Band  105 — 108 MHz (TX)
AT27599/02
M2 Band
 138— 141 MHz (RX)
E Band  68 — 88 MHz 
AT27599/03
E Band  68 — 88 MHz (TX)
AT27599/04
P8 Band
 96 — 106 MHz (RX)
C Band  117 — 137 MHz 
AT27599/02
Capacitors
1p7 ±.0p1
2p2 ±0p1
3p9
±0p25
4p7 ±0p25
6p8 ±0p25
8p2 ±0p5
8p2
±0p25
10p ..±5%
12p ±2%
12p
±5%
15p
±.2%
18p ±2%
22p
±5%
22p .±2%
27p ±5%
33p ±2%
33p ±5%
39p ±5%
47p
±5%
cer. tub  PN99533 
C2 — A Band
cer tub.
 PN99534  C2 — M1/M2,C Bands
cer. tub.  PN99537 
C2 — E Band
C4 — A,M1/M2,C Bands
cer. tub  PN99538 
C2 — E/P8 Band
cer. plate  PN99566  C7 — A Band
cer. tub.  PN99541 
C6 — A Band
cer. tub. 
PN99567

C7 — E Band
cer. tub.  PN99542
 C6 — M1/M2,C Bands
C4 — E Band
cer. plate 
PN99569  C1 — A Band
cer. tub.  PN99543  C4 — E/P8 Band
cer. plate
 PN99570  C7 — M1/M2,C Bands
cer. plate 
PN99571 
C1 — M1/M2,C Bands
cer. tub.  PN99546  C3,5 — A Band
cer. plate 
PN99572  C1 — E Band
cer. tub. 
PN99526
 C6 — E,E/P8 Bands
cer. plate 
PN99574 
C1 — E/P8 Bands
cer. tub.  PN99527  C3,5 — M1/M2,C Bands
cer. tub.  PN99528  C5 — E,E/P8 Bands
cer. tub. 
PN99529 
C3 — E,E/P8 Bands
Inductors
Coil  AT31233  L1,2 — A Band
Coil 
AT31247/02
 L1,2 — M1/M2,C Band
Coil  AT31242/01  L1 — E Band
Coil  AT31216/01  L1 — E/P8 Band
Coil  AT31242/02  L2 — E Band
Coil  AT31216/02  L2 — E/P8 Band
Coil  AT31234 
L3 — A Band
Coil  AT31247/03 
L3 — M1/M2,C Bands
Coil  AT31243/03  L3 — E Bands
Coil  AT31216/03  L3 — E/P8 Bands
Miscellaneous Items
PWB Assembly  AT12384/01
Contact  BT36841
Screen  BT26208
