Matrix 424/832/832+ LCD Programming Manual
RINS916-6 Page 15
5.3 Zone Type – Arm Mode A (Function 261)
5.4 Zone Type – Arm Mode B (Function 262)
5.5 Zone Type – Arm Mode C (Function 263)
5.6 Zone Type – Arm Mode D (Function 264)
Programming for Arm Mode A is shown.
Press .
ENTER ZONE No.
__
Enter the zone number to configure as a 2-digit
number (01 – 32). *If zone doubling is selected
it is possible to program up to 64 zones
Example shows Zone 01.
This display is quickly
followed by the next.
ENTER ZONE No.
01
The current zone type is displayed.
Use the and keys to scroll through the
zone types, or type a 2-digit zone code to select
the zone type.
Press to accept the zone type.
00 = ENTRY / EXIT
01 = ACCESS
02 = IMMEDIATE
03 = OMIT
04 = FIRE ALARM
05 = PERSONAL
ATTACK
06 = 24 HOUR
07 = KEY BOX
08 = SHUNT KEYPAD
09 = TAMPER
10 = LATCHED KEY
11 = MOMENTARY KEY
12 = UNUSED
13 = MEDICAL
14 = ARM
ARM MODE A
ENTRY/EXIT
DEFAULT ZONE TYPES
Zone Type Zone Type Zone Type Zone Type
1 Entry/Exit 9 Immediate 17 Immediate 25 Immediate
2 Access 10 Immediate 18 Immediate 26 Immediate
3 Immediate 11 Immediate 19 Immediate 27 Immediate
4 Immediate 12 Immediate 20 Immediate 28 Immediate
5 Immediate 13 Immediate 21 Immediate 29 Immediate
6 Immediate 14 Immediate 22 Immediate 30 Immediate
7 Immediate 15 Immediate 23 Immediate 31 Immediate
8 Immediate 16 Immediate 24 Immediate 32 Immediate
33 Immediate 41 Immediate 49 Immediate 57 Immediate
34 Immediate 42 Immediate 50 Immediate 58 Immediate
35 Immediate 43 Immediate 51 Immediate 59 Immediate
36 Immediate 44 Immediate 52 Immediate 60 Immediate
37 Immediate 45 Immediate 53 Immediate 61 Immediate
38 Immediate 46 Immediate 54 Immediate 62 Immediate
39 Immediate 47 Immediate 55 Immediate 63 Immediate
40 Immediate 48 Immediate 56 Immediate 64 Immediate
(In grey – zones that can only be used if Zone doubling is selected (See Function 250)
