Pyronix Matrix 832 Programming Manual

Matrix 424/832/832+ LCD Programming Manual
RINS916-6 Page 43
14.2 Telephone Format Only (Function 652)
Press .
This starts the function
CHOOSE TEL No.
_
Enter 1 digit to select the telephone number to
be changed.
Example shows
telephone number 1
This display is quickly
followed by the next
CHOOSE TEL No.
_1
The current report format setting is displayed.
Example shows 0
(Contact ID)
ENTER FORMAT No.
00
Enter 1 digit for the reporting format (1 – 4).
NOTE: A leading zero is always shown.
Example shows 1
(BSIA Fast Format)
ENTER FORMAT No.
01
Press  to accept the changes.
№ TYPE
0 Contact ID Format
1 BSIA Fast Format
2 Pyronix Format
3 Pager Format
4 Voice Format
Shaded = Default
14.3 BSIA Format Channel Map (Function 655)
Press .
The current map is
displayed
ENTER MAP INFO
_ 12345678
Enter 8 digits (1 – 8).
NOTE: All 8 digits MUST be different.
NOTE: The map is automatically accepte
d
after entering the 8
th
digit.
Example shows 1
(BSIA Fast Format)
ENTER MAP INFO
87654321
DIGITS ENTERED MEANING
1 Fire
2 PA
3 Intruder
4 Open/Close
5 Abort
6 Medical
7 Confirmed
8 Omit
