Matrix 424/832/832+ LCD Programming Manual
RINS916-6 Page 41
13.9 Test Dial Sequence (Function 608)
Press .
The current sequence is
displayed
ENTER DIAL ORDER
01
Enter 1 digit to select the sequence required.
NOTE: A leading zero is always shown.
Example shows
sequence 2
ENTER DIAL ORDER
02
Press to accept the changes.
SEQUENCE DESCRIPTION
1 Test dial sent to telephone number 1 only
2 Test dial sent to telephone 1 and 2
3 Test dial sent to telephone 1, and if no transmission, the to telephone 2
Shaded = Default
13.10 Anti-Code Algorithm (Function 609)
Press .
The current algorithm is
displayed
ENTER ALGORITHM
00
Enter 1 digit to select the algorithm required.
NOTE: A leading zero is always shown.
Example shows
algorithm 3
ENTER ALGORITHM
03
Press to accept the changes.
NOTE: Pyronix Anti-Code generating software will only generate codes for algorithm 0, an
therefore it is highly recommended that this setting is not altered.
13.11 Digital Communicator Options 2 (Function 610)
Press .
This starts the function
DIGI COMM OPT 2
OPTION 1 OFF
The current partition options are displayed.
Select any option by using the and keys,
or use the – keys to select that option
directly.
Press to toggle the option
ON
or
OFF
.
Press to accept the options.
There are 2 options
SYSTEM OPTIONS 1
OPTION 2 OFF
DIGI COMM OPT 2
OPTION 1 OFF
№ OPTION OFF OPTION ON
1
Do Not Delete Pending Events on Opening After
Alarm
Delete Pending Event on Opening After Alarm
2 Normal Event Dial Fast Event Dial
3 Event ReDials = 4 Event Redials = 8
4 Send All MX485 Reporting Follow Send Options for MX485 Reporting
5 Event Duplication = No Event Duplication = Yes
6
7
8
Reserved for future use.
Shaded = Default
