19. CONTACT ID EVENT CODES
Q EEE English Equivalent Matrix System Events PP NNN
Group 1: INTRUDER ALARMS
1 or 3 130 Burglary Immediate or Access Zone – Alarm / Restoral 01-04 001-032
1 or 3 133 24 Hour 24 Hour Zone – Alarm / Restoral 01-04 001-032
1 or 3 134 Entry / Exit Entry / Exit Zone – Alarm / Restoral 01-04 001-032
1 or 3 137 Tamper Global Tamper Loop (GT Input) – Alarm / Restoral 01-04 001
1 or 3 137 Tamper Keypress Tamper – Alarm / Restoral 01-04 003
1 or 3 143 Expansion Module Fault Remote Device Missing / Restoral (MX-IX16) 01-04 002
1 or 3 143 Expansion Module Fault Remote Device Missing / Restoral (MX-RIX16 – ID1) 01-04 061
1 or 3 143 Expansion Module Fault Remote Device Missing / Restoral (MX-RIX16 – ID2) 01-04 062
1 or 3 143 Expansion Module Fault Remote Device Missing / Restoral (MX-ROX8) 01-04 041
1 or 3 143 Expansion Module Fault Remote Device Missing / Restoral (MX-LCD) 01-04 001-004
1 or 3 143 Expansion Module Fault Remote Device Missing / Restoral (MX-LCD ICON) 01-04 011-014
1 or 3 143 Expansion Module Fault Remote Device Missing / Restoral (MX-PROX) 01-04 021-024
1 or 3 144 Sensor Tamper EOL Zone – Tamper / Restoral 01-04 001-032
1 or 3 146 Silent Burglary Immediate or Access Zone – Bell Delay Alarm /
Restoral
01-04 001-032
1 or 3 321 Bell Tamper Bell Tamper Loop (BT Input) – Alarm / Restoral 01-04 000
1 or 3 373 Tamper 2 Wire Fire Detector Loop (on PGM4) – Tamper /
Restoral
01-04 099
1 or 3 383 Sensor Tamper Tamper Zone – Alarm / Restoral (Internal alarm only /
no bell activation)
01-04 001-032
Group 2: PERSONAL ATTACK ALARMS
1 121 Duress Arm or Disarm by Duress User Code 01-04 001-032
1 or 3 122 Silent Panic Silent PA Alarm / Restoral from Keypad 01-04 000
1 or 3 122 Silent Panic Personal Attack Zone – Silent Alarm / Restoral 01-04 001-032
1 or 3 123 Audible Panic Audible PA Alarm / Restoral from Keypad 01-04 000
1 or 3 123 Audible Panic Personal Attack Zone – Audible Alarm / Restoral 01-04 001-032
Group 3: FIRE ALARMS
1 or 3 110 Fire Fire Alarm / Restoral from Keypad 01-04 000
1 or 3 110 Fire 2 Wire Fire Detector Loop (on PGM4) – Alarm /
Restoral
01-04 099
1 or 3 110 Fire Fire Zone – Alarm / Restoral 01-04 001-032
Group 4: MAINTENANCE
1 or 3 301 AC Power AC Mains – Fail / Restoral 01 000
1 or 3 302 Low Battery Battery Missing or Low Battery – Fail / Restoral 01 000
1 305 System Reset Panel Powered Up 01 000
1 or 3 344 Jam Detect RF Expander experiencing Jamming 01-04 000
1 or 3 381 Supervision Loss Detector stopped checking in 01-04 016-032
1 or 3 384 RF Low Battery Low battery in RF detector 01-04 016-032
1 412 Successful UDL Data was successfully uploaded from / downloaded
from panel
01 000
1 or 3 607 Walk Test Mode Walk Test Mode – Entered / Left 01-04 000
1 or 3 623 Event Log 90% Full Event Log 90% of Capacity 01 000
1 627 Program Mode Entry Engineer Mode Entered 01 099
1 628 Program Mode Exit Engineer Mode Left 01 099
Group 5: OPEN/CLOSE
1 or 3 401 User Open (Disarm) / Close (Arm) by User Code 01-04 001-032
1 or 3 401 User Open (Disarm) / Close (Arm) from Engineer Mode or
PC
01-04 099
1 403 Automatic Open (Disarm) by Partition Dependency 01-04 000
To Next Page
