Matrix 424/832/832+ LCD Programming Manual
Page 18 RINS916-6
6. USERS
6.1 User Code Partition (Function 300)
Press .
ENTER USER No.
__
Enter the 2-digit user number (01 – 32).
Example shows User 01.
This display is quickly
followed by the next.
ENTER USER No.
01
The current user partitions are displayed.
Select any option (partition) by using the
and keys, or use the – keys to
select that option directly.
Press to toggle the option
ON
or
OFF
.
Press to accept the options.
There are 4 options
SYSTEM OPTIONS 1
OPTION 4 OFF
SYSTEM OPTIONS 1
OPTION 3 OFF
SYSTEM OPTIONS 1
OPTION 2 OFF
CODE ALLOCATION
OPTION 1 ON
№ OPTION OFF OPTION ON
1 User Code Not Assigned to Partition 1 User Code Assigned to Partition 1
2 User Code Not Assigned to Partition 2 User Code Assigned to Partition 2
3 User Code Not Assigned to Partition 3 User Code Assigned to Partition 3
4 User Code Not Assigned to Partition 4 User Code Assigned to Partition 4
5
6
7
8
Reserved for Future Use. Do Not Alter.
Shaded = Default
To Next Page
