Pyronix Matrix 832 Programming Manual

Matrix 424/832/832+ LCD Programming Manual
Page 58 RINS916-6
17. DD243
17.1 DD243 Options 1 (Function 800)
Press .
This starts the function
DD243 OPT 1
OPTION 1 OFF
The current options are displayed.
Select any option by using the  and 
keys, or use the  –  keys to select that
option directly.
Press  to toggle the option
ON
or
OFF
.
Press  to accept the options.
There are 7 options
SYSTEM OPTIONS 1
OPTION 7 OFF
SYSTEM OPTIONS 1
OPTION 6 ON
SYSTEM OPTIONS 1
OPTION 5 ON
SYSTEM OPTIONS 1
OPTION 4 ON
SYSTEM OPTIONS 1
OPTION 3 ON
SYSTEM OPTIONS 1
OPTION 2 OFF
DD243 OPT 1
OPTION 1 OFF
№ OPTION OFF OPTION ON
1 Disable DD243 Options 2 – 8 Enable DD243 Options 2 – 8
2 Open Set Zone Does Not Stop Confirmation Open Set Zone Stops Confirmation
3 Open Entry Zone Does Not Stop Confirmation Open Entry Zone Stops Confirmation
4 Auto Omit Open Zones at End of Bell Time
Auto Omit Open Zones at End of Confirmation
Time
5
Lost Zone Expander Does Not Cause Confirmed
Alarm
Lost Zone Expander Causes Confirmed Alarm
6 Fire, PA & Medical Keys are Enabled Fire, PA & Medical Keys are Disabled
7 Entry Timer End Re-enables Confirmation
Entry Timer End Does Not Re-enable
Confirmation
8 Reserved for Future Use. Do Not Alter.
Shaded = Default
17.2 DD243 Zone Map (Function 802)
Press .
This starts the function
ENTER ZONE No.
__
Enter a 2-digit zone number (01 – 32).
Example shows zone 1
This display is quickly
followed by the next
ENTER ZONE No.
01
The current zone map number is displayed.
Example shows zone
map 01
DD243 ZONE MAP
01
Enter a new 2-digit zone map number (01 – 99).
Example shows zone
map 03
DD243 ZONE MAP
03
Press  to accept the changes.
