Matrix 424/832/832+ LCD Programming Manual

RINS916-6 Page 29

10.5 Home & Away Allocation (Function 454)

Press .

This starts the function

ENTER PARTITION

Enter 1 digit for the partition (1 – 4).

Example shows Partition

This display is quickly

followed by the next

ENTER PARTITION

The home & away options are displayed.

Select any option by using the  and 

keys, or use the  –  keys to select that

option directly.

Press  to toggle the option

OFF

Press  to accept the options.

There are 4 options

SYSTEM OPTIONS 1

OPTION 4 OFF

SYSTEM OPTIONS 1

OPTION 3 OFF

SYSTEM OPTIONS 1

OPTION 2 OFF

HOME & AWAY OPT

OPTION 1 ON

№ OPTION OFF OPTION ON

1 – Arm Mode A Home Away

2 – Arm Mode B Home Away

3 – Arm Mode C Home Away

4 – Arm Mode D Home Away

Reserved for Future Use. Do Not Alter.

Shaded = Default

Default Chapter3
