INSTALLING THE DRIVE SYSTEM
INSTALLING THE DRIVE SYSTEM
8
Move the carriage back and forth to
ensure the wheels are riding on their
tracks.
Place your sewing machine back on
the carriage and replace the handle
assembly.
The QBOT drive system is now installed.
Remove the black knob from the front
center of the handle assembly. Slide the
QBOT bracket onto the exposed bolt.
Replace and tighten the black knob to
hold your QBOT in place. Notice the
QBOT bracket is adjustable so that you
can move the QBOT to easily see the
screen in any light.
