Communication Protocol TCP/IP Communications Setup Command Set
CubiScan 125 Service Manual 76
TCP/IP Communications Setup Command Set
This section describes the commands recognized by the CubiScan 125 to set up the CubiScan 125
for communications with a network using the TCP/IP protocol.
You can use the Qbit, QbitTCP software to configure the CubiScan 125 for TCP/IP
communications. Contact Quantronix for information.
Configuration of the CubiScan 125 for TCP/IP communication is performed through the RS-232-
C serial communications port using the following commands.
Set Port
This command is used to set the CubiScan 125 TCP port number. In TCP/IP networks, port
numbers are used to distinguish between different logical channels on the same network
interface on the same computer. For example, port 80 is used for HTTP traffic on the Internet.
Some ports have numbers assigned to them by the Internet Assigned Numbers Authority (IANA).
These are known as “well-known ports” and are limited to numbers 0 through 1023. Ports 1024
through 49151 are “registered ports” listed by the IANA, and can be used by ordinary user
processes on most systems. Ports 49152 through 65535 are called “dynamic and/or private ports”
and are free for use. It is recommended that the CubiScan 125 TCP port be set to a number
4 1 Carriage Return Control (CR) 0Dh
51Line Feed Control(LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
21Zero Command Alpha (Z) 5Ah
3 1 Acknowledge Alpha (A) 41h
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
21Zero Command Alpha (Z) 5Ah
31Neg. Acknowledge Alpha (N) 4Eh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
