Quantum QXS G2 Series User Manual

Troubleshoot/Problem Solving 147
Ta b l e 33 Notes
•
1
This model uses a qualified FC SFP option within the CNC ports (used for host connection).
• When in FC mode, the SFPs must be a qualified 8Gb or 16Gb fiber-optic option.
• A 16Gb/s SFP can run at 16Gb/s, 8Gb/s, 4Gb/s, or auto-negotiate its link speed.
• An 8Gb/s SFP can run at 8Gb/s, 4Gb/s, or auto-negotiate its link speed.
•
2
This model uses a qualified 10GbE iSCSI option within the controller module CNC ports (used for
host connection).
•
3
This model uses a qualified 1Gb iSCSI SFP option within the controller module CNC ports (used
for host connection).
•
4
CNC ports support same-type or mixed-type SFPs in combination as described in RAID Controller
and Expansion IOMs on page 39.
5U 4-Port Controller RAID Chassis Matrix
Tabl e 3 4 provides the type of host attach for the 5U84 controllers in the RAID chassis.
Ta b l e 34 Notes
•
1
This model uses a qualified FC SFP option within the CNC ports (used for host connection).
• When in FC mode, the SFPs must be a qualified 8Gb or 16Gb fiber-optic option.
• A 16Gb/s SFP can run at 16Gb/s, 8Gb/s, 4Gb/s, or auto-negotiate its link speed.
• An 8Gb/s SFP can run at 8Gb/s, 4Gb/s, or auto-negotiate its link speed.
•
2
This model uses a qualified 10GbE iSCSI option within the controller module CNC ports (used for
host connection).
•
3
This model uses a qualified 1Gb iSCSI SFP option within the controller module CNC ports (used
for host connection).
•
4
CNC ports support same-type or mixed-type SFPs in combination as described in RAID Controller
and Expansion IOMs on page 39.
Ta b l e 3 4 5U 4-Port Controller RAID Chassis Matrix
2.5” (SFF)/3.5" (LFF) 84-Drive RAID Chassis
QXS-484 G2
System
Description Form
Fibre Channel (8/16Gb/s) SFP
1,4
5U84
Internet SCSI (10GbE) SFP
2,4
5U84
Internet SCSI (1Gb/s) SFP
3,4
5U84
