System Overview
This chapter provides information for the following 12-G QXS systems:
• QXS-G2-312: 12-Drive (2-Port: FC or iSCSI)
• QXS-G2-324: 24-Drive (2-Port: FC or iSCSI)
• QXS-G2-412: 12-Drive (4-Port: FC or iSCSI)
• QXS-G2-424: 24-Drive (4-Port: FC or iSCSI)
• QXS-G2-484: 84-Drive (4-Port: FC or iSCSI)
Chassis Configurations
The storage system supports three RAID chassis configurations.
• 2U12 (rack space) RAID chassis – see Figure 1:
• Holds up to 12 low profile (1-inch high) 3.5” form factor drives in a horizontal orientation.
• The 2U12 RAID chassis ships with 12 drives installed.
Figure 1 2U12-Drive System (Front)
