8 QXS G2 Hardware Installation and Maintenance Guide
Front and Rear Views of QXS G2 Systems
This section provides the front and rear views of the QXS G2 Systems.
2U12-Drive System
Figure 4 provides a front view of the 2U12-drive system.
Figure 4 2U12-Drive System (Front)
Figure 5 provides a rear view of the 2U12-drive system. The 2U12 RAID chassis has dual-controllers
(4-port FC/iSCSI model shown) installed.
Figure 5 2U12-Drive System (Rear)
2U12-Drive System Serial Number Label Location
This section provides the system serial number label location for the QXS G2 2U12-drive systems.
NOTE: If you need Quantum support, you will need your system serial number. The 2U12 and the
2U24-drive system serial number label locations are the same.
