Quickie puma 20 Technical Manual

Puma 20/40 Trouble shooting | 183
Trip Text
Trip
Code
Description
Memory Error -
This is a non specic memory error which could be caused by any of the modules within the
system.
• Check all cables and connections.
• Cycle the power.
If the trip is still present and the system contains 3rd party Modules:
• Disconnect all the non PGDT modules and cycle the power.
If this has cleared the trip:
• Connect each 3rd party module in turn, cycling the power each time.
• If the trip reappears after one of the power cycles then the last module to have been added to
the system must be defective.
If the trip is still present after the above checks have been made, then the PM may be
defective.
PM Memory Error -
This is a specic Power Module based trip.
• Check all cables and connections.
• Using the R-net PC Programmer, re-program the control system.
This should be done with either the most current specic program le for the wheelchair or the
manufacturers original programming le.
If the trip is still present after the above checks have been made, then the PM may be
defective.
Bad Cable -
This occurs when the control system detects a fault in the wiring in the communication cables
between any of the modules.
• Check all cables and connections for continuity.
• If there is any visible damage to cables, replace and cycle power.
• Disconnect one cable from the system at a time cycling the power after each disconnection.
If the trip is still present after the above checks have been made, then the PM may be
defective.
Bad Settings -
This occurs when the control system detects incorrect or invalid program settings.
• Check all parameter settings and re-program the control system using the R-net PC
Programmer.
• Make a note of the current parameter settings and then reset the control system to default
settings.
• Re-program the required settings in small groups, cycling the power after each group to see
if the trip occurs.
If the trip is still present after the above checks have been made, then the PM may be
defective.
Module Error -
This occurs when the control system detects a trip within a specic module. The module will be
identied on the diagnostics Screen.
• Check all cables and connections.
• Cycle the power.
If the trip is still present after the above checks have been made, then the module identied
may be defective.
System Error -
This occurs when the system detects a trip which cannot be attributed to a specic module.
• Check all cables and connections.
• Cycle the power.
If the trip is still present and the system contains 3rd party Modules:
• Disconnect all the none PGDT modules and cycle the power.
If this has cleared the trip:
• Connect each 3rd party module in turn, cycling the power each time.
• If the trip reappears after one of the power cycles then the last module to have been added to
the system must be defective.
If the trip is still present after the above checks have been made, then the PGDT control
system may be defective
SID Detached -
The Omni has detected that the Specialty Input Device (SID) has become disconnected.
• Check all cables and connectors between the Omni and the SID.
If the error persists:
• Check that the setting of the parameter, 9-Way Detect, is appropriate for the SID that is being
used. For example, if the SID has no detect-link, then this parameter should be set to Off.
If the trip is still present after the above checks have been made, then the Input Device may be
defective. Contact your service agent.
