Quickie puma 20 Technical Manual

Puma 20/40
Spare parts | 37
Pos Qty Article number Description
1,3-4 1 1016970 R-net direct access keypad joystick side
1-6 1 1016968 R-net direct access keypad joystick side, set
2,5-6 1 1016971 Direct access keypad bracket joystick side
3 2 - Spring washer M4 DIN127B VZ
3-4,7 1 1016973 R-net direct access keypad not joystick side
3-4,7-10 1 1016969 R-net direct access keypad not joystick side, set
4 2 - Round head screw with Phillips head M4x8 DIN7985
5 2 - Spring washer M5 DIN127B VZ
6 2 - Round head screw with Phillips head M5x16 DIN7985
8-10 1 1016972 Direct access keypad bracket not joystick side
10 2 1015330 Torx socket head screw M6x8 DIN7984 (100 pieces)
Pos Qty Article number Description
20 Direct access Puma 20/40 (all versions)
1
2
3
4
5
6
3
4
10
7
8
9
