Quickie puma 20 Technical Manual

Puma 20/40192 | Technical product information
7 Technical product information
7.1 CE Declaration and standards
This product complies with the COUNCIL DIRECTIVE 93/42/EEC of 14 June 1993
concerning medical devices. The product also meets the following requirements and standards. This
has been veried by independent test organizations.
Standard Denition/description Test dummy weight
EU guideline
93/42 EEC
93/42 EEC Requirements as stated in Appendix 1 apply n/a n/a
NEN-EN 12182
The EN 12182 requirements as stated in NEN-EN 12184 (2009):
Technical aids for disabled persons - General requirements and
test methods October 1999
Puma 20: 136 kg
Puma 40: 160 kg
NEN-EN 12184
(2009)
Class B
Electrically powered wheelchairs, scooters and their chargers -
Requirements and test methods October 2009
Puma 20: 136 kg
Puma 40: 160 kg
ISO 7176-8
Requirements and test methods for impact, static and fatigue
strengths July 1998
n/a
ISO 7176-9 Climatic tests for electric wheelchairs IPX4 n/a
ISO 7176-14
Requirements and test methods for power and control systems
for electrically powered wheelchairs 1997
n/a
ISO 7176-16 Requirements for resistance to ignition of upholstered parts May 1997 n/a
ISO 7176-19
(2008)
The Puma 20/40 meets the crash test requirements as described in
ISO 7176-19 (2008)
77 kg
7.2 Technical information
Batteries Max. Unit
Maximum battery dimensions 260 x 172 x 210 (10.2 x 6.8 x 8.3) mm (inch)
Maximum battery dimensions with Dahl system 260 x 172 x 190 (10.2 x 6.8 x 7.5) mm (inch)
Battery capacity 40 / 60 / 74 GEL; 50 AGM (Puma 20 only) Ah
Battery capacity with Dahl system 40 / 60 Ah
Maximum permissible charging voltage 24 V
Maximum charging current 12 A (rms)
Connector type Controller
Insulation Class 2 double insulated Class 2 double insulated
Model: PUMA 40 Sedeo Pro+ Class B
Description Unit FWD RWD
Maximum user weight kg (st.) 160 (25.2) 160 (25.2)
Maximum user weight with car docking kg (st.) 136 (21.4) 136 (21.4)
Total length including legrests mm (inch) 1160 (45.7) 1115 (43.9)
Total width 13” drive wheels
Total width 14” drive wheels
mm (inch)
mm (inch)
610 (24)
655 (25.8)
Total weight without batteries:
Batteries 40 Ah (C20) (set of two)
Batteries 60 Ah (C20) (set of two)
Batteries 74 Ah (C20) (set of two)
Electrical high/low adjustment
Electrical tilt adjustment
Electrically elevating central legrest
Electrically elevating legrests
Car docking
Puncture-proof drive wheels (set of two)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
87,3 (13.7)
+ 28,4 (4.5)
+ 34,6 (5.5)
+ 45,8 (7.2)
+ 18,8 (3)
+ 9,8 (1.5)
+ 9,5 (1.5)
+ 4 (8.8)
+ 4,5 (0.7)
+ 8,4 (1.3)
Transport weight of the heaviest part kg (st.) 83,9 (13.2)
All mesurements of dimensions etc. should be considered as value with a average tolerance of 1%
* The following aspects have a negative effect on the distance range: obstacles, rugged terrain, driving on slopes, exposure to temperatures
below freezing point and frequent use of electronic adjustment options.
** Seat height incl. load, 0° set angle and 13" drive wheels
