Quickie puma 20 Technical Manual

Puma 20/40 Technical product information | 193
Model: PUMA 40 Sedeo Pro+ Class B
Description Unit FWD RWD
Maximum safe slope ° 6
Static stability
Downwards
Upwards
Sidewards
°
°
°
18
15
10
Reversing distance mm (inch) 1180 (46.5) 1700 (66.9)
Turning radius (ISO 7176-5) mm (inch) 585 (23) 850 (33.5)
Distance range* 74 Ah (C20) approx. (ISO 7176-4)
6 km/h
10 km/h
km (mi.)
km (mi.)
42,5 (26.4)
37,2 (23.1)
Climbing capacity for obstacles (outdoor) mm (inch) 60 (2.4) 80 (3.1)
Maximum speed forwards km/h 6 / 10 (3.7 / 6.2)
Seat angle adjustment ° 0 - 6
Electrical tilt adjustment ° 0 - 45
Effective seat depth mm (inch) 440 - 600 (17.3- 23.6)
Effective seat width mm (inch) 380 - 600 (15 - 23.6)
Seat height (excl. cushion)** mm (inch) 405 / 430 / 455 / 480 / 505 (15.9 / 16.9 / 17.9 / 18.9 / 19.9)
Seat height (incl. cushion)** mm (inch) 475 / 500 / 525 / 550 / 575 (18.7 / 19.7 / 20.7 / 21.7 / 22.6)
Backrest recline ° 90 - 135
Backrest height mm (inch) 480 - 670 (18.9 - 26.4)
Lower leg length standard legrest (with compressed
seat cushion)
mm (inch) 340 - 510 (13.4 - 20.1)
All mesurements of dimensions etc. should be considered as value with a average tolerance of 1%
* The following aspects have a negative effect on the distance range: obstacles, rugged terrain, driving on slopes, exposure to temperatures
below freezing point and frequent use of electronic adjustment options.
** Seat height incl. load, 0° set angle and 13" drive wheels
Model: PUMA 40 Sedeo Pro Class B
Description Unit FWD RWD
Maximum user weight kg (st.) 160 (25.2) 160 (25.2)
Total length including legrests mm (inch) 1190 (46.9) 1115 (43.9)
Total width 13” drive wheels
Total width 14” drive wheels
mm (inch)
mm (inch)
610 (24)
655 (25.8)
Total weight without batteries:
Batteries 40 Ah (C20) (set of two)
Batteries 60 Ah (C20) (set of two)
Batteries 74 Ah (C20) (set of two)
Electrical high/low adjustment
Electrical tilt adjustment
Electrically reclining backrest
Electrically elevating legrests
Puncture-proof drive wheels (set of two)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
kg (st.)
97,6 (15.4)
+ 28,4 (4.5)
+ 34,6 (5.5)
+ 45,8 (7.2)
+ 18,8 (3)
+ 9,8 (1.5)
+ 1,5 (3.3)
+ 4 (8.8)
+ 8,4 (1.3)
Transport weight of the heaviest part kg (st.) 97,6 (15.4)
Maximum safe slope ° (%) 10 (17.6)
Static stability
Downwards
Upwards
Sidewards
°
°
°
15
15
15
Reversing distance mm (inch) 1200 (47.2) 1700 (66.9)
Turning radius (incl. footrests) mm (inch) 600 (23.6) 850 (33.5)
Distance range* 74 Ah (C20) approx. (ISO 7176-4)
6 km/h
10 km/h
12,5 km/h
km (mi.)
km (mi.)
km (mi.)
49,9 (31)
43,7 (27.2)
39,9 (24.8)
All mesurements of dimensions etc. should be considered as value with a average tolerance of 1%
* The following aspects have a negative effect on the distance range: obstacles, rugged terrain, driving on slopes, exposure to temperatures
below freezing point and frequent use of electronic adjustment options.
** Seat height incl. load, 0° seat angle and 13" drive wheels
