QM-7 SERIES SERVICE MANUAL
PAGE 3.7
JANUARY 2012SUNRISE MEDICAL
Section 3
A joystick trip is indicated. Make sure that the joystick is in the center position before switching on the
control system. Check that the batteries are fully charged and in good condition, examine the joystick
for damage. This fault can also be caused by a joystick that fails to center itself due to being dirty,
bent or broken. If this is the case, replace the joystick module.
Note: If replacing the joystick does not resolve the issue, replace the cable connecting the joystick to
the controller.
Seven Bars - Possible Joystick Trip
The onboard batteries are being charged with the off-board charger. You will not be able to drive the
wheelchar until the charger is disconnected. You will have to reset the control system by switching
off the power and then powering up again. The On-Board charger has no indication that the chair
is charging, and the chair will not move until complete. If the condition still exists after the charger
has been diconnected, and the chair has been switched off and then powered up again, the Joystick
module may be defective.
Six Bars - Charger Connected
Seven Bars + Speed Profile Indicator error
Inspect the wiring between joystick module and controller. Replace a jumper or joystick module that
has damaged wiring. If the problem persists replace the controller.
Controller Fault - A control system trip is indicated. Make sure that all connections are secure. Check
that the batteries are fully charged and in good condition, and check all joystick connections and
cables. If this does not correct the problem,disconnect the power to the controller for 2 minutes, replug
in to reboot the module. If the condition still exits, then replace the controller.
Eight Bars - Possible Control System Trip
