Section VIII - Technical data
• Readings on display
• Electric cable size and fuses
• Reference conditions and limitations
• Vacuum pump data
• Technical data Airlogic controller
Readings on display
Airlogic Graphic controller
Important
NOTICE!
The readings mentioned below are valid under the reference conditions (see section
Reference conditions and limitations).
Reference Reading
Vacuum pressure Depends on the setpoint (desired net pressure).
Element outlet temperature Approx. 83°C (181°F) (ambient temperature 20 °C + 63°C)
Discharge pressure Approx. 1020mbar(a)
96 Quincy Vacuum Pump-QSV Series
