Section III - Airlogic Graphic Controller
• Select Modify using the Scroll keys and press the Enter key. Next, modify the
password as required.
Programmable settings
Vacuum pump/motor
MiniMuM setting
Factory setting
MaxiMuM setting
set-point 1 and 2, Workplace vacuuM puMps
Mbar(a)
0 50 1000
set-point 1 and 2, Workplace vacuuM puMps
torr
0 37,5 750
indirect stop level
Mbar
5 10 100
indirect stop level
torr
3,75 7,5 75
proportional band
% 5 10 15
integration tiMe
sec
0,5 5 10
Parameters
MiniMuM setting
Factory setting
MaxiMuM setting
run tiMe at MiniMuM presure
sec
0 30 300
MaxiMuM pre purge tiMe
Min
1 15 20
MaxiMuM post purge tiMe
Min
1 30 180
MaxiMuM pre purge tiMe during operation
sec
1 120 600
Manual purge tiMe
Min
0 30 120
MiniMuM stop tiMe
sec
5 5 30
poWer recovery tiMe
sec
10 10 3600
restart delay
sec
0 0 1200
coMMunication tiMe-out
sec
10 30 60
Fan Motor starts per day (air-cooled vacuuM
puMps)
1 240 240
Protections
MiniMuM setting
Factory setting
MaxiMuM setting
vacuuM puMp eleMent outlet teMperature
(shut-doWn Warning level)
°c 50 110 119
vacuuM puMp eleMent outlet teMperature
(shut-doWn Warning level)
°F 122 230 246
vacuuM puMp eleMent outlet teMperature
(shut-doWn level)
°c 111 120 120
vacuuM puMp eleMent outlet teMperature
(shut-doWn level)
°F 232 248 248
Service plan
The built-in service timers will give a Service warning message after their respective pre-
programmed time interval has elapsed.
For specific data, see section Preventive Maintenance.
Consult Quincy if a timer setting needs to be changed. The intervals must not exceed
the nominal intervals and must coincide logically. See section Modifying general settings.
