Section III - Airlogic Graphic Controller
Modifying general settings
Control panel
(1) Scroll keys
(2) Enter key
(3) Escape key
Menu icon, Settings
Function
To display and modify a number of settings..
Procedure
Starting from the Main screen,
• Move the cursor to the action button Menu and press the Enter key. Following screen
appears:
• Next, move the cursor to the Settings icon (see above, section menu icon).using the
Scroll keys.
Quincy Vacuum Pump-QSV Series 45
