Section IV - Installation
Maximum contact load: 10 A / 250 V AC.
Stop the vacuum pump and switch off the voltage before connecting external
equipment. Consult Quincy.
Pictographs
Figure 6 Pictographs
Reference Designation
1 Switch off the voltage and depressurize the vacuum pump before starting maintenance
or Repairs
2 Lightly oil the gasket of the oil lter, screw it on and tighten by hand (approx. half a
turn)
3 Warning, hot surface
4 Stop the vacuum pump before cleaning the coolers
5 Warning, voltage
6 Switch off the voltage and wait at least 10 minutes before maintenance
7 vacuum pump remains pressurized for 180 seconds after switching off the voltage
8 If the rotation direction is wrong, open the isolating switch in the voltage supply line
and reverse two incoming electric lines
70 Quincy Vacuum Pump-QSV Series
