Section III - Airlogic Graphic Controller
Control mode selection
Control panel
(1) Scroll keys
(2) Enter key
(3) Escape key
Function
To select the control mode, i.e. whether the vacuum pump is in local control, remote
control or controlled via a local area network (LAN).
Procedure
Starting from the main screen, make sure the button Menu (iv) is selected:
Next, use the scroll buttons to go to the regulation icon (ii) and press the enter button:
34 Quincy Vacuum Pump-QSV Series
