Section IV - Installation
Installation proposal
A ( 1 : 10 )
A
1m
0,2m
ALT. 2
ALT. 4
ALT. 3
Allow sufficient space (1m of clearance on all sides and top of the vacuum pump)
for safe and proper installation, daily inspection and maintenance.
ALT. 1
ISOLATION VALVE
Outlet cooling air
Inlet cooling air
64 Quincy Vacuum Pump-QSV Series
