Section III - Airlogic Graphic Controller
Text on figures
(i) Menu
(ii) Regulation
• Move the cursor to the out puts icon (see above, section Menu icon, using the scroll
keys(1)
• Press the enter key (2), a screen similar to the one below appears:
(i) Outputs
(ii) Modulating Valve
(iii) Gas ballast
Quincy Vacuum Pump-QSV Series 31
