Sy
clone Portable Gamma-Ray Spectrometer, Revision 10 6.0 SYCLONE SPECIFICATIONS
Ra
dComm – Proprietary Page 48 Revision Date: March 3, 2016
DATA OUTPUT
Type: USB or Bluetooth (optional).
Format: Binary data in packets
USER INTERFACE
Control: Single Multifunction Joystick (All functions and features)
Display Type: TFT Color LCD,
QVGA (320 x 240 resolution)
Display Viewing Area: 3.5” Diagonal
Menus/Screens: English, Chinese, Japanese, Spanish, German
POWER
Adapter Voltage: 5VDC
Internal Source: Rechargeable Batteries – Manufacturers’ Lithium Battery
Capacity: 4800mAh, 3.7V
Operating Time: Rechargeable batteries – up to 12 hrs(typical 9 hours)
Battery Charging: typically 4 hours, full charge indication by Battery Icon
CONNECTORS
COMM Port: mini USB data transfer / charging
PHYSICAL
Dimensions: Length – 7.75" (197mm)
Width – 3.5" (89mm)
Height - 3" (76mm), 5.59" (142mm) including handle
Weight: 1.7 kg (3.7lbs) including batteries
ENVIRONMENTAL
Operating Temperature Range: -4°F to 122°F (-20°C to +50°C)
Storage Temperature Range: -4°F to 140°F (-20°C to +60°C)
Protection: Weatherproof, dust sealed, water splash-proof
Relative Humidity: 93% non-condensing at 104°F (40°C)
Vibration: 2 g for 15 min at 10 – 33 Hz in XYZ directions (ANSI N42.34)
Shock: Complies with ANSI N42.34
EM Compatibility: ANSI N42.34 compliant
CE compliant (EU safety, RFI and EMI directives)
FCC CFR 47, Part 15, Subpart B, Class B compliant
ACCESSORIES
