Part # MJ-SPDIFIN StudioHub+ S/PDIF to AES/EBU Converter
(856) 467-8000
•
Fax (856) 467-3044
•
www.studiohub.com
* RCA S/PDIF output
StudioHub+ AES/EBU RJ-45 input
JU1
Install to connect
shield ground to
power ground
